MSI MEG Z890 UNIFY-X DDR5 LGA 1851 WIFI 7 ATX MOTHERBOARD

MSI MEG Z890 UNIFY-X DDR5 LGA 1851 WIFI 7 ATX MOTHERBOARD

$1,059.00
$1,059.00
Sale Sold out

šŸ›  Chipset & CPU Support:

  • Chipset: Intel Z890

  • CPU Support: IntelĀ® Coreā„¢ Ultra Processors (Series 2)

  • Socket: LGA 1851

šŸ’¾ Memory Specifications:

  • Memory Slots: 2x DDR5 UDIMM, up to 128GB

  • Supported Speeds:

    • Overclocked: 9600 - 6400 MT/s

    • JEDEC: 6400 - 4800 MT/s

  • Overclocking Frequency:

    • 1DPC 1R: Up to 9600+ MT/s

    • 1DPC 2R: Up to 7200+ MT/s

Supports IntelĀ® XMP 3.0, Non-ECC, Un-buffered memory, CUDIMM

šŸŽ® Graphics & Display:

  • 2x Type-C DisplayPort (Thunderbolt 4): 4K @ 120Hz / 8K @ 60Hz (UHBR20)

*Available only on CPUs with integrated graphics.

šŸ”Œ Expansion Slots:

  • PCI_E1 (Gen 4, x1): From Chipset

  • PCI_E2 (Gen 5, x16): From CPU

  • PCI_E3 (Gen 5, x8): From CPU

  • PCI_E4 (Gen 4, x4): From Chipset

šŸŽ§ Audio:

  • RealtekĀ® ALC4080 Codec

  • 7.1-Channel USB High-Performance Audio

  • S/PDIF Output

  • 32-Bit / 384 kHz Playback (Front Panel)

šŸ’½ Storage Support:

  • M.2 Slots (6x):

    • M.2_1: PCIe 4.0 x4 (CPU) - 2280/2260

    • M.2_2: PCIe 4.0 x4 (Chipset) - 2280/2260

    • M.2_3: PCIe 4.0 x4 (Chipset) - 2280/2260

    • M.2_4: PCIe 5.0 x4 + PCIe 4.0 x4 (CPU + Chipset) - 22110/2280/2260

    • M.2_5: PCIe 4.0 x4 / SATA Mode (Chipset) - 2280/2260

    • M.2_6: PCIe 5.0 x4 (CPU) - 2280/2260

  • SATA: 6x SATA 6G

*RAID Support for SATA & M.2: RAID 0, 1, 5, 10

āš” Thunderbolt & USB Connectivity:

  • 2x Thunderboltā„¢ 4 (40Gbps / Type-C): Supports up to 8K display, Daisy-Chain (3x Thunderbolt 4 / 5x Thunderbolt 3)

  • USB Ports:

    • 4x USB 2.0 (Front)

    • 4x USB 5Gbps Type-A (Front)

    • 8x USB 10Gbps Type-A (Rear)

    • 2x USB 10Gbps Type-C (Rear)

    • 1x USB 20Gbps Type-C (Front)

šŸŒ Networking & Wireless:

  • LAN: 1x IntelĀ® Killer E5000B 5G LAN

  • Wi-Fi / Bluetooth: IntelĀ® Killerā„¢ BE1750x Wi-Fi 7, Bluetooth 5.4

šŸ”§ Internal Connectors:

  • 1x ATX Power Connector

  • 2x CPU Power Connectors

  • 1x PCIe Power Connector (8-pin)

  • 1x USB 20Gbps Type-C Front Connector

  • 1x CPU Fan

  • 2x Combo Fan (Pump / Sys Fan)

  • 4x System Fan

  • 1x Front Audio

  • 1x TPM Header (TPM 2.0)

  • 1x Water Flow Connector

  • 1x Chassis Intrusion

  • 3x ARGB V2 Headers

  • 1x RGB Header

šŸ›  Debugging & Monitoring:

  • 4x EZ Debug LED

  • 1x EZ Digit Debug LED

šŸ“¦ Package Dimensions & Form Factor:

  • Form Factor: ATX (243.84mm x 304.8mm)
