GIGABYTE RADEON™ RX 9070 GAMING OC 16G GRAPHICS CARD

🔧 Specifications

• GPU: AMD Radeon RX 9070 (Navi 48)

• Architecture: RDNA 4, manufactured using TSMC's 4nm N4P process

• Stream Processors: 3,584

• Ray Accelerators: 56

• Tensor Cores: 112

• Base Clock: 1,440 MHz

• Game Clock: 2,210 MHz

• Boost Clock: Up to 2,700 MHz (factory overclocked)

• Memory: 16 GB GDDR6

• Memory Interface: 256-bit

• Memory Speed: 20.1 Gbps effective

• Memory Bandwidth: 644.6 GB/s

• Bus Interface: PCIe 5.0 x16

• Display Outputs: 2 x DisplayPort 2.1, 2 x HDMI 2.1

• Maximum Resolution: 7680 x 4320 (8K)

• Power Connectors: 3 x 8-pin PCIe

• Recommended PSU: 850W

❄️ Cooling & Design

• Cooling System: WINDFORCE with Hawk fans, server-grade thermal conductive gel, composite copper heat pipes, large vapor chamber, 3D active fans, and screen cooling

• RGB Lighting: Customizable RGB lighting for aesthetics

• Dual BIOS: Switch between Performance and Silent modes

• Reinforced Structure: Enhanced durability and anti-sag design

📐 Dimensions & Weight

• Length: 288 mm (11.3 inches)

• Width: 132 mm (5.2 inches)

• Height: 56 mm (2.2 inches)

• Slot Width: Triple-slot

• Weight: Approximately 1.26 kg (2.78 lbs)

🧠 Performance & Features

• Ray Tracing & AI: Enhanced ray tracing capabilities and AI-driven features with AMD's latest technologies

• AMD HYPR-RX6: Instantly enables supported performance-boosting and latency-reducing technologies across numerous games

• FSR 4: Advanced upscaling technology for improved frame rates and image quality

• DirectX 12 Ultimate Support: Ensures compatibility with the latest gaming features
